Key features

  • Fully compatible with renewable technologies
  • Inbuilt control system enables custom efficiency programming
  • Live fault reporting to enable quick repair
  • Economy mode allows dual set point controls to maximise efficiency
  • Peak 1 hour supply 288-1081 litres/hour @50°C temperature rise
  • Zero on site emissions
  • Up to 9 electrical elements with cascade control
  • BMS connections a standard
  • Built in redundancy to eliminate downtime

ANCILLARY OPTIONS

  • Correx non-sacrificial anode kits
  • De-stratification pump sets
  • Unvented system kits

Brief product specifications

Storage Capacity173 litres
Efficiency (Part L2 Gross CV)100 %
Nominal Input - Gross9 kW
Height1420 mm
Diameter560 mm
Weight - Empty73 Kg
Storage Capacity173 litres
Efficiency (Part L2 Gross CV)100 %
Nominal Input - Gross18 kW
Height1420 mm
Diameter560 mm
Weight - Empty73 Kg
Storage Capacity173 litres
Efficiency (Part L2 Gross CV)100 %
Nominal Input - Gross36 kW
Height1420 mm
Diameter559 mm
Weight - Empty110 Kg
Storage Capacity264 litres
Nominal Input - Gross9 kW
Height1540 mm
Diameter640 mm
Weight - Empty110 Kg
Storage Capacity264 litres
Nominal Input - Gross18 kW
Height1539 mm
Diameter640 mm
Weight - Empty110 Kg
Storage Capacity264 litres
Nominal Input - Gross36 kW
Height1540 mm
Diameter640 mm
Weight - Empty110 Kg
Storage Capacity264 litres
Nominal Input - Gross54 kW
Height1540 mm
Diameter640 mm
Weight - Empty110 Kg
