Key features

  • Heating capacity ranging from 22 to 464kW
  • Designed to supply low temperature heating systems
  • Suitable for hybrid systems including LTHW and DHW applications
  • COP up to 4.61
  • SCOP up to 4.13
  • Stage compressors

Advanced integral controls including:

  • BMS fault and remote on/off signal
  • MODBUS protocol compatibility
  • Indirect water heater control with DHW priority
  • Anti-legionella programme

The efficiency of a heat pump is often expressed as COP; this is the ratio of heat output available from a single unit of heat input. Amicus LT have COP of up to 4.61, which could also be described as an efficiency of up to 461%. COP is calculated at a specific ambient temperature of 7°C and at a flow temperature of 30 to 35°C.

Heating capacity can therefore fluctuate according to ambient temperature with output reducing in lower temperatures, but increasing in higher temperatures. Amicus LT units can operate in temperatures as low as -20°C.

ANCILLARY OPTIONS

  • Anti-vibration dampers
  • Remote control panel
  • Electronic soft start
  • Thermal stores

Brief product specifications

LAHP-252LT

Heating capacity22.2 kW
Height1468 mm
Width875 mm
Depth1915 mm
Weight - Empty560 Kg

LAHP-302LT

Heating capacity29.6 kW
Height1468 mm
Width875 mm
Depth1915 mm
Weight - Empty560 Kg

LAHP-402LT

Heating capacity37.3 kW
Height1677 mm
Width875 mm
Depth2115 mm
Weight - Empty670 Kg

LAHP-452LT

Heating capacity47.1 kW
Height1677 mm
Width875 mm
Depth2115 mm
Weight - Empty690 Kg

LAHP-502LT

Heating capacity50.8 kW
Height1677 mm
Width875 mm
Depth2115 mm
Weight - Empty720 Kg

LAHP-602LT

Heating capacity61.2 kW
Height1840 mm
Width1146 mm
Depth2905 mm
Weight - Empty1060 Kg

LAHP-702LT

Heating capacity67.3 kW
Height1840 mm
Width1146 mm
Depth2905 mm
Weight - Empty1060 Kg

LAHP-802LT

Heating capacity74.9 kW
Height1840 mm
Width1146 mm
Depth2905 mm
Weight - Empty1070 Kg

LAHP-902LT

Heating capacity93.2 kW
Height1892 mm
Width1145 mm
Depth2905 mm
Weight - Empty1120 Kg

LAHP-1002LT

Heating capacity104.9 kW
Height1892 mm
Width1145 mm
Depth2905 mm
Weight - Empty1160 Kg

LAHP-1202LT

Heating capacity114.9 kW
Height1892 mm
Width1145 mm
Depth2905 mm
Weight - Empty1240 Kg

LAHP-1402LT

Heating capacity137.1 kW
Height1894 mm
Width1145 mm
Depth3905 mm
Weight - Empty1560 Kg

LAHP-1602LT

Heating capacity151 kW
Height1894 mm
Width1145 mm
Depth3905 mm
Weight - Empty1580 Kg

LAHP-1802LT

Heating capacity167.9 kW
Height1894 mm
Width1145 mm
Depth3905 mm
Weight - Empty1600 Kg

LAHP-2002LT

Heating capacity182.8 kW
Height1894 mm
Width1145 mm
Depth3905 mm
Weight - Empty1620 Kg

LAHP-2302LT

Heating capacity210.6 kW
Height2294 mm
Width1145 mm
Depth3905 mm
Weight - Empty1790 Kg

LAHP-2502LT

Heating capacity241.3 kW
Height2294 mm
Width1145 mm
Depth3905 mm
Weight - Empty1820 Kg

LAHP-2504LT

Heating capacity229.4 kW
Height2356 mm
Width2190 mm
Depth4205 mm
Weight - Empty3170 Kg

LAHP-3004LT

Heating capacity271.4 kW
Height2356 mm
Width2190 mm
Depth4205 mm
Weight - Empty3220 Kg

LAHP-3204LT

Heating capacity296.7 kW
Height2356 mm
Width2190 mm
Depth4205 mm
Weight - Empty3270 Kg

LAHP-3504LT

Heating capacity339 kW
Height2356 mm
Width2190 mm
Depth4205 mm
Weight - Empty3320 Kg

LAHP-4004LT

Heating capacity364.9 kW
Height2371 mm
Width2190 mm
Depth4805 mm
Weight - Empty3660 Kg

LAHP-4504LT

Heating capacity407 kW
Height2371 mm
Width2190 mm
Depth4805 mm
Weight - Empty3720 Kg

LAHP-5004LT

Heating capacity463.7 kW
Height2371 mm
Width2190 mm
Depth4805 mm
Weight - Empty3780 Kg
